517 • DM NAX® Product Manual — Doc. 9045M
4. To set the port number, do one of the following:
l
Click the arrows to increase or decrease the port number by increments of 1.
l
Manually enter a port number in the Port field. The default port number is 5004.
5. Click OK to save or click Cancel to cancel the changes.
Routing
The Routing section is used to route a local input or AES67 stream to a Zone on the DM-NAX-AUD-IO.
NOTE: To receive an AES67 stream from Dante devices, see OLH 1001151.
To route an input to a zone, click the box in the routing matrix where the zone's row overlaps the
corresponding input's column. Once a route is made, appears. To break a given route click or .
To route a single input to all zones, click on the icon under the input's name.
Security
Click the Security tab to configure security for users and groups and to allow different levels of access
to the DM-NAX-AUD-IO functions. By default, security is disabled.
