459 • DM NAX® Product Manual — Doc. 9045M
l
Under the Transmitters section (see Configure Transmitters), the last two listed transmitters
are dedicated to parallel zone outputs.
l
To configure the DSP settings, see Zone Settings.
Click NAXStreams to display the following information.
l
Device is Master PTP Clock Source indicates whether the device is the master for PTP on the
network. Yes will be displayed in green when the local DM-NAX-AMP-X300 is the PTP clock
master and No will be displayed in red when another PTP clock on the network is operating as the
master clock.
l
Master Clock Status displays the Master Clock ID of the device on the network that acts as the
Master Clock.
l
PTP Priority: This sets the priority of the local DMNAX device's PTP clock relative to other clocks
on the network. The default setting is 254 (one increment higher than the lowest possible value)
so that the DM-NAX-AMP-X300 will only operate as clock master if no other PTP master is
present on the network. Valid values range from 1 to 255.
Configure Transmitters
To configure a DM NAX transmit stream, do the following.
1. Enter a valid multicast address in the NAX Stream Address field.
2. Enter a name in the NAX Stream Name field by which the stream can be identified. This stream
name is associated with the DMNAX stream's multicast address by other DMNAX or AES67
devices, like a device hostname that resolves to a given IPaddress.
