Observe the LED Indicators
Refer to the following table for information about the LED indicators on the device.
LED Indicator Color Meaning
PWR Amber Power is being applied to the device. Thedevice is
booting.
White Device is powered on with audio passing.
Red Device is in standby mode.
Ethernet 1 and 2 White The device is powered on and has a valid IP address.
Off Device is not connected to a network or the IP address is
invalid.
SOURCE 1-4 White Signal is detected on the specified input/source.
Red There is clipping on an analog input or bitstream audio
detected on a digital input.
Off There is no signal detected on the specified input/source.
ZONE 1-4 White There is audio output on the indicated zone.
Red Clipping or a fault is detected on the zone output due to
over current, over temperature, or low voltage.
ZONE 5 White There is audio output on the indicated zone.
Red Clipping is detected on the zone output due to over
current, over temperature, or low voltage.
SETUP Solid Red The SETUP button is pressed.
Blinking Red A network reset or factory restore has been initiated via
the adjacent SETUP button.
Reset the Device
A network reset or factory restore may be performed when troubleshooting.
CAUTION: These procedures should only be performed as a last resort to recover an unresponsive
device. Both the Network Reset and Factory Restore procedure will clear certain device settings that
cannot be recovered once the procedure is complete. Before performing these procedures, please
contact Crestron True Blue Support via phone, email or chat as described at
www.crestron.com/support.
Network Reset
1. Ensure the device is powered on.
2. Press and hold the SETUP button for up to 15 seconds until the SETUP LEDflashes red.
