Product Manual — Doc. 9045M DM NAX® • 79
LED Indicator Color Meaning
LAN White The device is powered on and has a valid IP address.
Off Device is not connected to a network or the IP address is
invalid.
NAX White AoIP is ready to pass and the unit's PTP clock is synced.
Off No AoIP is passing to or from and/or PTP is not synced.
SOURCE 1-8 White Signal is detected on the specified input/source.
Red There is clipping on an analog input or bitstream audio
detected on a digital input.
Off There is no signal detected on the specified input/source.
ZONE 1-8 White There is audio output on the indicated zone.
Red Clipping or a fault is detected on the zone output due to
over current, over temperature, or low voltage.
SETUP Solid Red The SETUP button is pressed.
Blinking Red A network reset or factory restore has been initiated via
the adjacent SETUP button.
