xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1039
tx_rate - (Optional) Specifies the limitation of transmit data rate.
no_limit - Specifies to indicate there is no limit on port tx bandwidth.
<value 8-10240000> - Enter an integer value from 8 to 10240000 to set a maximum limit in
Kbits/sec. The specified bandwidth limit may be equaled but not exceeded. This exact
logical limit or token value is hardware determined.
percent – Specifies the TX percentage rate value.
<value 1-100> - Enter the percentage rate value here. This value must be between 1 and 100
percent.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Examples
This example shows how to configure the port bandwidth.
DGS-3620-28PC:admin#config bandwidth_control 1-10 tx_rate 1024
Command: config bandwidth_control 1-10 tx_rate 1024
Success.
DGS-3620-28PC:admin#
This example shows how to configure the TX bandwidth rate on ports 1 to 10 to be 10%.
DGS-3620-28PC:admin# config bandwidth_control 1:1-1:10 tx_rate percent 10
Command: config bandwidth_control 1:1-1:10 tx_rate percent 10
Success.
DGS-3620-28PC:admin#
91-2 show bandwidth_control
Description
This command is used to display the port bandwidth configurations. The bandwidth can also be
assigned by the RADIUS server through the authentication process. If the RADIUS server has
assigned the bandwidth, then the RADIUS-assigned bandwidth will be the effective bandwidth.
Format
show bandwidth_control {<portlist>}
Parameters
<portlist> - (Optional) Specifies a range of ports to be displayed.
Note: If no parameter is specified, the system will display all port bandwidth
configurations.
