To show the scheduling mechanism on ports 1-10:
DGS-3620-28PC:admin#show scheduling_mechanism 1-10
Command: show scheduling_mechanism 1-10
Port Mode
----- ------
1 Strict
2 Strict
3 Strict
4 Strict
5 Strict
6 Strict
7 Strict
8 Strict
9 Strict
10 Strict
DGS-3620-28PC:admin#
91-9 config 802.1p user_priority
Description
This command is used to configure the way by which the switch will map an incoming packet,
based on its 802.1p user priority, to one of the eight available hardware priority queues on the
switch. The switch’s default is to map the following incoming 802.1p user priority values to the
eight hardware priority queues. The suggested mapping is shown in the following table. Users can
change this mapping by specifying the 802.1p user priority to assign to the <class_id>.
Priority in Frames
Priority Queue of ASIC
Remark
0
2
Mid-Low
1
0
Lowest
2
1
Lowest
3
3
Mid-Low
4
4
Mid-High
5
5
Mid-High
6
6
Highest
7
7
Highest
Format
config 802.1p user_priority {ports [<portlist> | all]} <priority 0-7> <class_id 0-7>
Parameters
ports - (Optional) Specifies that port used for this configuration.
portlist - Specifies the range of ports to be configured.
