xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
103
offset_chunk_1 - Specifies the offset chunk 1 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 1 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 1 mask value here.
offset_chunk_2 - Specifies the offset chunk 2 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 2 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 2 mask value here.
offset_chunk_3 - Specifies the offset chunk 3 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 3 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 3 mask value here.
offset_chunk_4 - Specifies the offset chunk 4 that allows users to examine the specified
offset_chunks within a packet at one time and specifies the frame content offset and mask.
<value 0-31> - Enter the offset chunk 4 value here. This value must be between 0 and 31.
<hex 0x0-0xffffffff> - Enter the offset chunk 4 mask value here.
ipv6 - Specifies the IPv6 filtering mask.
class - Specifies the IPv6 class mask.
flowlabel - Specifies the IPv6 flow label mask.
source_ipv6_mask - Specifies the IPv6 source IP mask.
<ipv6mask> - Enter the IPv6 source IP mask.
destination_ipv6_mask - Specifies the IPv6 destination IP mask.
<ipv6mask> - Enter the IPv6 destination IP mask.
tcp - Specifies that the rule applies to TCP traffic.
src_port_mask - (Optional) Specifies the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask.
dst_port_mask - (Optional) Specifies the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask.
udp - Specifies that the rule applies to UDP traffic.
src_port_mask - (Optional) Specifies the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask.
dst_port_mask - (Optional) Specifies the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask.
icmp - Specifies that the rule applies to ICMP traffic.
type - (Optional) Specifies the ICMP packet type.
code - (Optional) Specifies the ICMP code.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To create access list profiles:
DGS-3620-28PC:admin#create access_profile profile_id 1 profile_name 1 ethernet
vlan source_mac FF-FF-FF-FF-FF-FF destination_mac 00-00-00-FF-FF-FF 802.1p
ethernet_type
Command: create access_profile profile_id 1 profile_name 1 ethernet vlan
source_mac FF-FF-FF-FF-FF-FF destination_mac 00-00-00-FF-FF-FF 802.1p
ethernet_type
Success.
DGS-3620-28PC:admin#
DGS-3620-28PC:admin#create access_profile profile_id 2 profile_name 2 ip vlan
source_ip_mask 255.255.255.255 destination_ip_mask 255.255.255.0 dscp icmp
