xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1252
Format
traceroute [<ipaddr> | <domain_name 255>] {ttl <value 1-60> | port <value 30000-64900> |
timeout <sec 1-65535> | probe <value 1-9>}
Parameters
<ipaddr> - Enter the IP address of the destination end station.
<domain_name 255> - Enter the domain name of the destination end station.
ttl - (Optional) Specifies the time to live value of the trace route request.
<value 1-60> - Enter the time to live value of the trace route request. This is the maximum
number of routers that a trace route packet can pass while seeking the network path
between two devices. The range for the TTL is 1 to 60 hops. The default value is 30.
port - (Optional) Specifies the port number.
<value 30000-649000> - Enter the port number. The value range is from 30000 to 64900. The
default is 33435.
timeout - (Optional) Specifies the timeout period while waiting for a response from the remote
device.
<sec 1-65535> - Enter the timeout period while waiting for a response from the remote device.
A value of 1 to 65535 seconds can be specified. The default is 5 seconds.
probe (Optional) Specifies the number of probes.
<value 1-9> - Enter the number of probes. The range is from 1 to 9. If unspecified, the default
value is 1.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To trace the route path between the switch and 10.48.74.121:
DGS-3620-28PC:admin#traceroute 10.48.74.121 probe 3
Command: traceroute 10.48.74.121 probe 3
<10 ms 10.12.73.254
<10 ms 10.12.73.254
<10 ms 10.12.73.254
<10 ms 10.19.68.1
<10 ms 10.19.68.1
<10 ms 10.19.68.1
<10 ms 10.48.74.121
Trace complete.
DGS-3620-28PC:admin#
119-19 traceroute6
Description
This command is used to trace the IPv6 routed path between the Switch and a destination end
station.
