xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

742

PFC Basic Configuration

Willing : Disabled

MBC : Disabled

PFC capability : 8

PFC Enable

priority0 : Disabled

priority1 : Disabled

priority2 : Disabled

priority3 : Disabled

priority4 : Disabled

priority5 : Disabled

priority6 : Disabled

priority7 : Disabled

DGS-3620-28PC:admin#
