User's Manual
122
Table 6-26 Database linkage parameters
Icon/Parameter Description
The selected database is enabled by default. Click the icon to
disable it.
Delete the database.
Alarm Rule Click to select a color for the alarm rule box.
Display Feature Pane
Select the checkbox to enable the features pane. The features pane
appears on the live video once there is an alarm.
3) Click
Select
next to
Event Linkage
to set alarm actions.
Step 9 Click
Save
.
6.8.5 Live View of Plate Comparison
View plate comparison results under the
Live
tab.
6.8.5.1 Setting Attribute Display
Set the display rules of detection results.
Make sure that view is created before setting AI display. To create view, see "7.1.1 View
Management".
Procedure
Step 1 Log in to the PC client.
Step 2 Under the
Live
tab, open a view window.
Step 3 Click and then select the
Motor Vehicle
tab.
