User's Manual
186
Parameter Description
Port Mapping List
The list is consistent with the UPnP port mapping list on the router.
●
Internal Port
: The ports of the IVSS to be mapped on the router.
●
External Port
: The ports mapped on the router. Click , and then
you can modify the external ports.
●
When setting the external port, use the ports between 1024 and
5000, and do not use the well-known ports 1 to 255 and the system
ports 256 to 1023, otherwise conflicts might occur.
●
When there are multiple devices on the LAN, properly plan the port
mapping to avoid conflicts in WAN ports.
●
When making a port mapping, make sure that the port you are
mapping is not occupied or restricted.
●
The TCP/UDP WAN and LAN ports must be consistent and cannot be
modified.
Step 5 Click
Apply
.
Enter http://
WAN IP: WAN port number
in the browser to access the Device with the
corresponding port number on the router network.
8.2.2.6 SNMP
After setting SNMP (Simple Network Management Protocol) and successfully connecting the Device
through relevant software tools such as MIB Builder, and MG-SOFT MIB Browser, you can directly
manage and monitor the Device on the software tools.
Prerequisites
●
Install SNMP monitoring and management tools, such as MIB Builder and MG-SOFT MIB Browser.
●
Obtain the MIB file corresponding to the current version from technical support.
Procedure
Step 1 Log in to the PC client.
Step 2 Click on the upper-right corner and then click
Network
.
You can also click
Network
from the configuration list on the home page.
Step 3 Select
Network Application
>
SNMP
.
