User's Manual
195
Action Description Preparation
Remote Warning Light
When a linkage event occurs,
the system associates with the
remote device to turn on the
warning light.
The remote device that
supports this function has
been connected. For details,
see "8.3.1.13 Remote Warning
Light".
8.3.1.1 Record
Enable record control function. The system links the selected remote device to record when a
linkage event occurs.
Make sure that a remote device, such as IPC, has been added. See "5.5.2 Adding Remote Devices" for
detailed information.
Procedure
Step 1 On the alarm configuration page, click
Select
next to
Event Linkage
, and then select
Record
.
Figure 8-28 Record
Step 2 Set the time length of recording after the event moment.
Step 3 In the
Device
box, select one or more remote devices for linkage recording.
Step 4 Click
Apply
.
8.3.1.2 Buzzer
The system activates a buzzer alarm when a linkage event occurs.
On the alarm configuration page, click
Select
next to
Event Linkage
, select
Buzzer
, and then click
Apply
.
Figure 8-29 Buzzer
8.3.1.3 Log
Enable the log function. The system notes down the alarm information in the log when a linkage
event occurs.
On the alarm configuration page, click
Select
next to
Event Linkage
, select
Log
, and then click
Apply
.
