User's Manual
13
Figure 2-16 IVSS7016 rear panel (redundant power)
Figure 2-17 IVSS7016-M rear panel (single power)
Figure 2-18 IVSS7016-M rear panel (redundant power)
Table 2-6 IVSS7016 rear panel description
No. Name Description
1 Power input port Inputs 100–240 VAC power.
2 AI module indicator light
Displays AI module status.
●
The yellow light flashes: AI module is
running properly.
●
The yellow light is on: AI module is
malfunctioning.
This function is valid if there is AI module.
