User's Manual
24
No. Name Description
Alarm Output
8 groups of alarm output ports (NO1 C1NO8 C8).
They output alarm signal to the alarm device. Please
make sure there is power to the external alarm
device.
NO: Alarm output port of Normally Open type.
C: Common alarm output port.
: GND end.
3 Network port
10/100/1000Mbps self-adaptive Ethernet port.
Connects to the network cable.
4 USB port
Connects to external devices such as USB storage
device, keyboard and mouse.
5 RS-232 port
RS-232 COM debug. It is used for general COM
debug, setting IP address, and transmitting
transparent COM data.
6 PCI-E X4 PCI Express port. It supports X4 slot.
7 VGA port
VGA video output port. It outputs analog video
signal. The VGA port and HDMI 1 port are same
source output.
8 eSATA port
SATA peripheral port. Connects to SATA port or
eSATA device.
9
AUDIO IN Audio input port.
AUDIO OUT Audio output port
10 HDMI port
High definition audio and video signal output port.
The port outputs the uncompressed high definition
video and multi-channel audio data to the
connected display with HDMI port. The two HDMI
ports are different source output.
11 AI module indicator light
Displays AI module status.
The yellow light flashes: AI module is running
properly.
The yellow light is on: AI module is
malfunctioning.
This function is not available without AI module.
