User's Manual
235
Figure 8-21 TCP/IP
Step 2 Click of the corresponding NIC to edit network parameters.
Figure 8-22 Edit Ethernet network
Step 3 Set parameters.
Table 8-6 TCP/IP parameters description
Speed Current NIC max network transmission speed.
IP Type Select IPv4 or IPv6.
Use Dynamic IP
Address
When there is a DHCP server on the network, check the box to use
dynamic IP address, system can allocate a dynamic IP address to the
device. There is no need to set IP address manually.
Use Static IP Address
Check the box to use static IP address. Set static IP address, subnet mask
and gateway. Set a static IP address for the device.
Test Test whether the IP address is valid.
