Routing Commands | 395
Example
Figure 22-127. show arp Command Example
Report Fields Age Time (seconds)—The time, in seconds, for an ARP entry to age out, as configured into the unit.
Response Time (seconds)—The time, in seconds, it takes for an ARP request timeout, as configured
into the unit
Retries—The maximum number of times an ARP request is retried, as configured into the unit
Cache Size—The maximum number of entries in the ARP table. This value was configured into the unit
Dynamic Renew Mode—Displays whether the ARP component automatically attempts to renew
dynamic ARP entries when they age out
Total Entry Count Current / Peak—The total entries in the ARP table and the peak entry count in the
ARP table
Static Entry Count Current / Max—The static entry count in the ARP table and maximum static entry
count in the ARP table
The following are displayed for each ARP entry:
IP Address—The IP address of a device on a subnet attached to an existing routing interface
MAC Address—The hardware MAC address of that device
Interface—The routing
unit/slot/port associated with the device ARP entry
Type—The type that was configured into the unit. The possible values are Local, Gateway, Dynamic and
Static.
Age—The current age of the ARP entry since last refresh (in hh:mm:ss format)
show arp brief
This command displays the brief Address Resolution Protocol (ARP) table information.
Syntax
show arp brief
Mode
Privileged Exec
(Force10 ) #show arp
Age Time (seconds)............................. 1200
Response Time (seconds)........................ 1
Retries........................................ 4
Cache Size..................................... 1920
Dynamic Renew Mode ............................ Enable
Total Entry Count Current / Peak .............. 0 / 0
Static Entry Count Configured / Active / Max .. 0 / 0 / 64
IP Address MAC Address Interface Type Age
--------------- ----------------- ----------- -------- -----------
Related
Commands
show arp brief Displays summary Address Resolution Protocol (ARP) information
show arp switch Displays connectivity between the switch and other devices
