Connect the Front End for a Dual-Controller Storage Center
Dell Compellent 109
 ControllerB,slot2,port1→Fabric1
3 ConfigureFCzoningtomeetthelegacymodezoningrequirements.
Figure 94. Dual-controller with Single-Fabric FC in Virtual Port Mode
See Also
RequirementsforVirtualPortModeonpage 97
FibreChannelZoningonpage 10 2
Controller B
Fabric 1
Server 1
Controller A
Server 2
1 2
1 2
