Delta VFD-E Series User Manual

Chapter 4 Parameters 
4-97
 Multi-Step Speed
ON ON ON ON ON ON ON ON
ONONONON
ON
ON
ON
ON
05.00
05.01
05.02
05.03
05.04
05.05
05.06
05.07
05.08
05.09
05.10
05.11
05.12
05.13
05.14
01.15
OFF
OFF
OFF
OFF
OFF
123456789101112131415
M
u
l
t
i
-
f
u
n
c
t
i
o
n
t
e
r
m
i
n
a
l
s
0
4
.
0
5
~
0
4
.
0
8
Frequency
Master Speed
JOG Freq.
2nd speed
( 2)MI3 to MI6
1st speed
( to MI6 1)MI3
Jog Freq.
Multi-speed via External Terminals
Run/Stop
PU/external terminals
/communication
3rd speed
( 3)MI3 to MI6
4th speed
( 4)MI3 to MI6
MI6=4 MI5=3 MI4=2 MI3=1
Master frequency OFF OFF OFF OFF
1
st
speed OFF OFF OFF ON
2
nd
speed OFF OFF ON OFF
3
rd
speed OFF OFF ON ON
4
th
speed OFF ON OFF OFF
5
th
speed OFF ON OFF ON
6
th
speed OFF ON ON OFF
7
th
speed OFF ON ON ON
8
th
speed ON OFF OFF OFF
9
th
speed ON OFF OFF ON
10
th
speed ON OFF ON OFF
11
th
speed ON OFF ON ON
12
th
speed ON ON OFF OFF
13
th
speed ON ON OFF ON
14
th
speed ON ON ON OFF
15
th
speed ON ON ON ON
