Delta VFD-E Series User Manual

B-8
B.3 AC Reactor
B.3.1 AC Input & Output Reactor Recommended Value
115V, 50/60Hz,
Model
kW
[HP]
Rated
Amps
Fundamental
Amps
3% impedance
(mH)
5% impedance
(mH)
3% input reactor
Delta Part. No.
002
0.2
[0.25]
1.6 2.4 0.686 1.1439 N/A
004
0.4
[0.5]
2.5 3.75 0.439 0.7321 N/A
007
0.75
[1]
4.2 6.3 0.261 0.4358 N/A
200~230V, 50/60Hz,
Model
kW
[HP]
Rated
Amps
Fundamental
Amps
3% impedance
(mH)
5% impedance
(mH)
3% input reactor
Delta Part. No.
3-phase 1-phase 3-phase 1-phase 3-phase 1-phase 3-phase 1-phase 3-phase 1-phase
002
0.2
[0.25]
1.9 4.9 2.85 7.35 5.562 3.735 9.269 6.225 N/A N/A
004
0.4
[0.5]
2.7 6.5 4.05 10.4 3.913 2.816 6.523 4.693 N/A N/A
007
0.75
[1]
5.1 9.7 7.65 15.52 2.113 1.887 3.522 3.145 N/A N/A
015
1.5
[2]
9 15.7 13.5 25.12 1.321 1.166 2.201 1.943 N/A N/A
022
2.2
[3]
15 24 22.5 38.4 0.704 0.763 1.174 1.271 N/A N/A
037
3.7
[5]
20.6 - 30.9 - 0.622 - 1.036 - N/A -
055
5.5
[7.5]
26 - 39 - 0.423 - 0.704 - N/A -
075
7.5
[10]
34 - 51 - 0.320 - 0.534 - DR033AP320 -
110
11
[15]
48 - 72 - 0.216 - 0.359 - DR049AP215 -
150
15
[20]
70 - 105 - 0.163 - 0.271 - DR065AP162 -
380~460V, 50/60Hz,
Model
kW
[HP]
Rated
Amps
Fundamental
Amps
3% impedance
(mH)
5% impedance
(mH)
3% input reactor
Delta Part. No.
004
0.4
[0.5]
1.5 2.3 14.090 23.483 N/A
007
0.75
[1]
2.5 3.8 7.045 11.741 N/A
015
1.5
[2]
4.2 6.3 5.284 8.806 N/A
022
2.2
[3]
5.5 8.3 3.522 5.871 N/A
037
3.7
[5]
8.5 12.8 2.348 3.914 N/A
055
5.5
[7.5]
13 19.5 1.761 2.935 N/A
075
7.5
[10]
18 27 1.174 1.957 DR018A0117
110
11
[15]
24 36 0.881 1.468 DR024AP880
150
15
[20]
32 48 0.660 1.101 DR032AP660
185
18.5
[25]
38 57 0.556 0.927 N/A
220
22
[30]
45 67.5 0.470 0.783 N/A
