Delta VFD-E Series User Manual

Chapter 4 Parameters 
4-4
Group 1 Basic Parameters
Parameter Explanation Settings
Factory
Setting
Customer
01.00
Maximum Output
Frequency (Fmax)
50.00 to 599.00 Hz
60.00
01.01
Maximum Voltage
Frequency (Fbase)
(Motor 0)
0.10 to 599.00 Hz 60.00
01.02
Maximum Output
Voltage (Vmax)
(Motor 0)
115V/230V series: 0.1V to 255.0V 220.0
460V series: 0.1V to 510.0V 440.0
01.03
Mid-Point Frequency
(Fmid) (Motor 0)
0.10 to 599.00 Hz
1.50
01.04
Mid-Point Voltage
(Vmid) (Motor 0)
115V/230V series: 0.1V to 255.0V 10.0
460V series: 0.1V to 510.0V 20.0
01.05
Minimum Output
Frequency (Fmin)
(Motor 0)
0.10 to 599.00 Hz
1.50
01.06
Minimum Output
Voltage (Vmin)
(Motor 0)
115V/230V series: 0.1V to 255.0V 10.0
460V series: 0.1V to 510.0V 20.0
01.07
Output Frequency
Upper Limit
0.1 to 120.0%
110.0
01.08
Output Frequency
Lower Limit
0.0 to100.0 %
0.0
01.09 Accel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
01.10 Decel Time 1 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
01.11 Accel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
01.12 Decel Time 2 0.1 to 600.0 / 0.01 to 600.0 sec 10.0
01.13 Jog Acceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
01.14 Jog Deceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
01.15 Jog Frequency 0.10 Hz to 599.00 Hz
6.00
01.16
Auto acceleration /
0: Linear Accel/Decel
0
