Delta VFD-E Series User Manual

D-55
D.5.9 Description of the Application Commands
API
Mnemonic
Codes
P
Command
Function
Steps
16 bits 32 bits 16-bit 32-bit
Transmission
Comparison
10 CMP --

Compare 7 --
11 ZCP --

Zone compare 9 --
12 MOV --

Data Move 5 --
15 BMOV --

Block move 7 --
Four
Fundamental
Operations of
Arithmetic
20 ADD --

Perform the addition of
BIN data
7 --
21 SUB --

Perform the subtraction
of BIN data
7 --
22 MUL --

Perform the
multiplication of BIN
data
7 --
23 DIV --

Perform the division of
BIN data
7 --
24 INC --

Perform the addition of
1
3 --
25 DEC --

Perform the subtraction
of 1
3 --
Rotation and
Displacement
30 ROR --

Rotate to the right 5 --
31 ROL --

Rotate to the left 5 --
Special
command for
AC motor
drive
53 -- DHSCS X
High speed counter
enable
-- 13
139 RPR --

Control PID parameters
of inverter
5 --
140 WPR --

Control frequency of
inverter
5 --
141 FPID --

Read the parameter 9 --
142 FREQ --

Write the parameter 7 --
