Delta VFD-E Series User Manual

Chapter 4 Parameters 
4-7
Group 2 Operation Method Parameters
Parameter Explanation Settings
Factory
Setting
Customer
02.00
Source of First
Master Frequency
Command
0: Digital keypad UP/DOWN keys or Multi-
function Inputs UP/DOWN. Last used
frequency saved.
1: 0 to +10V from AVI
2: 4 to 20mA from ACI or 0 to +10V from
AVI2
3: RS-485 (RJ-45)/USB communication
4: Digital keypad potentiometer
1
02.01
Source of First
Operation
Command
0: Digital keypad
1
1: External terminals. Keypad STOP/RESET
enabled.
2: External terminals. Keypad STOP/RESET
disabled.
3: RS-485 (RJ-45)/USB communication.
Keypad STOP/RESET enabled.
4: RS-485 (RJ-45)/USB communication.
Keypad STOP/RESET disabled.
02.02 Stop Method
0: STOP: ramp to stop; E.F.: coast to stop
0
1: STOP: coast to stop; E.F.: coast to stop
2: STOP: ramp to stop; E.F.: ramp to stop
3: STOP: coast to stop; E.F.: ramp to stop
02.03
PWM Carrier
Frequency
Selections
1 to 15kHz 8
02.04
Motor Direction
Control
0: Enable forward/reverse operation
0
1: Disable reverse operation
2: Disabled forward operation
