Delta VFD-E Series User Manual

Chapter 4 Parameters 
4-37
Group 13: PG function Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
13.00 PG Input
0: Disabled
0
1: Single phase
2: Forward/Counterclockwise rotation
3: Reverse/Clockwise rotation
13.01 PG Pulse Range 1 to 20000 600
13.02
Motor Pole Number
(Motor 0)
2 to 10 4
13.03
Proportional Gain
(P)
0.0 to 10.0 1.0
13.04
Integral Gain (I) 0.00 to 100.00 sec 1.00
13.05
Speed Control
Output Frequency
Limit
0.00 to 100.00Hz 10.00
13.06
Speed Feedback
Display Filter
0 to 9999 (*2ms) 500
13.07
Detection Time for
Feedback Signal
Fault
0.0: disabled
0.1 to 10.0 sec
1.0
13.08
Treatment of the
Feedback Signal
Fault
0: Warn and RAMP to stop
1
1: Warn and COAST to stop
2: Warn and keep operation
13.09
Speed Feedback
Filter
0 to 9999 (*2ms) 16
13.10
Source of the High-
speed Counter
0: PG card
Read
Only
1: PLC (NOT for VFD*E*C models)
