Delta VFD-E Series User Manual

A-1
Appendix A: Specifications
There are 115V, 230V and 460V models in the VFD-E series. For 115V models, it is 1-phase
models. For 0.25 to 3HP of the 230V models, there are 1-phase/3-phase models. Refer to following
specifications for details.
Voltage Class
115V Class
Model Number VFD-XXXE
002
004
007
Max. Applicable Motor Output (kW)
0.2
0.4
0.75
Max. Applicable Motor Output (hp)
0.25
0.5
1.0
Output Rating
Rated Output Capacity (kVA)
0.6
1.0
1.6
Rated Output Current (A)
1.6
2.5
4.2
Maximum Output Voltage (V)
3-Phase Proportional to Twice the Input Voltage
Output Frequency (Hz)
0.10~ 599.00 Hz
Carrier Frequency (kHz)
1-15
Input Rating
Rated Input Current (A)
Single-phase
6
9
18
Rated Voltage/Frequency
Single phase, 100-120V, 50/60Hz
Voltage Tolerance

10%(90~132 V)
Frequency Tolerance

5%(47~63 Hz)
Cooling Method
Natural Cooling
Fan Cooling
Weight (kg)
1.2
1.2
1.2
Voltage Class
230V Class
Model Number VFD-XXXE
002
004
007
015
022
037
055
075
110
150
Max. Applicable Motor Output
(kW)
0.2
0.4
0.75
1.5
2.2
3.7
5.5
7.5
11
15
Max. Applicable Motor Output (hp)
0.25
0.5
1.0
2.0
3.0
5.0
7.5
10
15
20
Output Rating
Rated Output Capacity (kVA)
0.6
1.0
1.6
2.9
4.2
6.5
9.5
12.5
17.1
25
Rated Output Current (A)
1.6
2.5
4.2
7.5
11.0
17
25
33
45
65
Maximum Output Voltage (V)
3-Phase Proportional to Input Voltage
Output Frequency (Hz)
0.10~ 599.00 Hz
Carrier Frequency (kHz)
1-15
Input Rating
Rated Input Current (A)
Single/3-phase
3-phase
4.9/1.9
6.5/2.7
9.5/5.1
15.7/9
24/15
20.6
26
34
48
70
Rated Voltage/Frequency
Single/3-phase
200-240 V, 50/60Hz
3-phase
200-240V, 50/60Hz
Voltage Tolerance

10%(180~264 V)
Frequency Tolerance

5%(47~63 Hz)
Cooling Method
Natural Cooling
Fan Cooling
Weight (kg)
1.1
1.1
1.1
1.9
1.9
1.9
3.5
3.5
3.57
6.6
