D.5 Commands
D.5.1 Basic Commands
Commands Function Operands processing Speed(us)
LD Load contact A X, Y, M, T, C 10
LDI Load contact B X, Y, M, T, C 10
AND Series connection with A contact X, Y, M, T, C 10
ANI Series connection with B contact X, Y, M, T, C 10
OR Parallel connection with A contact X, Y, M, T, C 10
ORI Parallel connection with B contact X, Y, M, T, C 10
ANB Series connects the circuit block -- 4
ORB Parallel connects the circuit block
--
4
MPS Save the operation result
--
4
MRD
Read the operation result (the pointer not
moving)
--
4
MPP Read the result
--
4
INV Inverter the result -- 4
D.5.2 Output Commands
Commands Function Operands
processing Speed(us)
OUT Drive coil Y, M 14
SET Action latched (ON) Y, M 14
RST Clear the contacts or the registers Y, M, T, C, D 18
D.5.3 Timer and Counters
Commands Function Operands
processing Speed(us)
TMR 16-bit timer T-K or T-D
32
CNT 16-bit counter C-K or C-D
37
