Chapter 4 Parameters
4-114
19 Power Board CPU READ Failure (cF2.0)
20 CC, OC Hardware protection failure (HPF1)
21 OV Hardware protection failure (HPF2)
22 GFF Hardware protection failure (HPF3)
23 OC Hardware protection failure (HPF4)
24 U-phase fault (cF3.0)
25 V-phase fault (cF3.1)
26 W-phase fault (cF3.2)
27 DCBUS fault (cF3.3)
28 IGBT Overheat (cF3.4)
29 Reserved
30 Control Board CPU WRITE failure (cF1.1)
31 Contrsol Board CPU READ failure (cF2.1)
32 ACI signal fault (AErr)
33 Reserved
34 Motor PTC overheat protection (PtC1)
35 PG feedback signal fault (PGEr)
36-39 Reserved
40 Communication time-out fault of control board and power board
(CP10)
41 dEb fault
42 ACL (Abnormal Communication Loop)
66 U phase output phase loss (oPHL1)
67 V phase output phase loss (oPHL2)
68 W phase output phase loss (oPHL3)
In Pr.06.08 to Pr.06.12 the five most recent faults that occurred, are stored. After removing the
cause of the fault, use the reset command to reset the drive.
06.13 Action for detected Output Phase Loss (OPHL)
Factory Setting: 3
Settings 0 Warn and keep operation
1 Warn and ramp to stop
2 Warn and coast to stop
3 No warning
06.14 Deceleration Time of Output Phase Loss Unit: second
Settings 0.0 ~120.0 seconds Factory Setting: 0.5
