Delta VFD-E Series - Main Control Commands; Rising-Edge;Falling-Edge Detection Commands of Contact; Rising-Edge;Falling-Edge Output Commands; End Command

D-40
D.5.4 Main Control Commands
Commands Function Operands
MC
Connect the common series connection
contacts
N0~N7
MCR
Disconnect the common series connection
contacts
N0~N7
D.5.5 Rising-edge/falling-edge Detection Commands of Contact
Commands Function Operands
LDP Rising-edge detection operation starts
X, Y, M, T, C
LDF Falling-edge detection operation starts
X, Y, M, T, C
ANDP Rising-edge detection series connection
X, Y, M, T, C
ANDF Falling-edge detection series connection
X, Y, M, T, C
ORP Rising-edge detection parallel connection
X, Y, M, T, C
ORF Falling-edge detection parallel connection
X, Y, M, T, C
D.5.6 Rising-edge/falling-edge Output Commands
Commands Function Operands
PLS Rising-edge output Y, M
PLF Falling-edge output Y, M
D.5.7 End Command
Command Function Operands
END Program end none
