D-61
API Mnemonic Operands Function
21 SUB P S
1
, S
2
,
D Subtraction
Type
OP
Bit Devices Word devices Program Steps
X Y M K H KnX KnY KnM T C D SUB, SUBP: 7 steps
DSUB, DSUBP: 13 steps
S
1
* * * * * * * *
S
2
* * * * * * * *
D * * * * *
Operands:
S1: Minuend S2: Subtrahend D: Remainder
Explanations:
1. This instruction subtracts S1 and S2 in BIN format and stores the result in D.
2. The highest bit is symbolic bit 0 (+) and 1 (-), which is suitable for algebraic subtraction.
3. Flag changes in binary subtraction
In 16-bit instruction:
A. If the operation result ＝ 0, zero flag M1020 = On.
B. If the operation result ＜ -32,768, borrow flag M1021 = On.
C. If the operation result ＞ 32,767, carry flag M1022 = On.
Program Example:
In 16-bit BIN subtraction:
When X0 = On, the content in D0 will minus the content in D10 and the remainder will be stored in
D20.
X0
SUB D0 D10 D20
To Next Page
