D-63
API Mnemonic Operands Function
23 DIV P S
1
, S
2
,
D Division
Type
OP
Bit Devices Word devices Program Steps
X Y M K H KnX KnY KnM T C D DIV, DIVP: 7 steps
S
1
* * * * * * * *
S
2
* * * * * * * *
D * * * * *
Operands:
S
1
: Dividend S
2
: Divisor D: Quotient and remainder
Explanations:
1. In 16-bit instruction, D occupies 2 consecutive devices.
2. This instruction divides S
1
and S
2
in BIN format and stores the result in D. Be careful with
the positive/negative signs of S
1
, S
2
and D when doing 16-bit and 32-bit operations.
16-bit instruction:
+1
Quotient
Remainder
Program Example:
When X0 = On, D0 will be divided by D10 and the quotient will be stored in D20 and remainder in
D21. On/Off of the highest bit indicates the positive/negative status of the result value.
X0
DIV D0 D10 D20
D0 D10 K4Y0
DIV
