Delta VFD-E Series

B-36
LED double
flash
On for 0.2s off for 0.2s, on for 0.2s and off for 1s
B.8.4 MKE-HUB01
In order to improve the reliability for multiple communication wiring, Delta has developed a
special communication hub MKE-HUB01.
Please refer to the following diagram for operating and wiring：
12345678 12345678
12345678
Jack 1 Jack 2
US PLU
G
