Delta VFD-E Series - Parameters for Extension Card

Chapter 4 Parameters 
4-31
Group 11 Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
11.00
Multi-function
Output Terminal
MO2/RA2
0: No function
0
1: AC drive operational
2: Master frequency attained
3: Zero speed
11.01
Multi-function
Output Terminal
MO3/RA3
4: Over torque detection
0
5: Base-Block (B.B.) indication
6: Low-voltage indication
7: Operation mode indication
11.02
Multi-function
Output Terminal
MO4/RA4
8: Fault indication
9: Desired frequency 1 attained
0
10: Terminal count value attained
11: Preliminary count value attained
11.03
Multi-function
Output Terminal
MO5/RA5
12: Over Voltage Stall supervision
0
13: Over Current Stall supervision
14: IGBT overheat warning (ON: 85℃, OFF:
80℃)
15: Over Voltage supervision
11.04
Multi-function
Output Terminal
MO6/RA6
16: PID supervision
0
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
11.05
Multi-function
Output Terminal
MO7/RA7
21: Brake control (Desired frequency
attained)
0
22: Drive ready
23: Desired frequency 2 attained
24 :Function of output frequency control
multi-output terminal ON/OFF
