Delta VFD-E Series - Page 87

Chapter 4 Parameters 
4-32
Parameter Explanation Settings
Factory
Setting
Customer
11.06
Multi-function Input
Terminal (MI7)
0: No function 0
1: Multi-Step speed command 1
2: Multi-Step speed command 2
11.07
Multi-function Input
Terminal (MI8)
3: Multi-Step speed command 3 0
4: Multi-Step speed command 4
5: External reset
11.08
Multi-function Input
Terminal (MI9)
6: Accel/Decel inhibit 0
7: Accel/Decel time selection command
8: Jog Operation
11.09
Multi-function Input
Terminal (MI10)
9: External base block 0
10: Up: Increment master frequency
11: Down: Decrement master frequency
11.10
Multi-function Input
Terminal (MI11)
12: Counter Trigger Signal 0
13: Counter reset
14: E.F. External Fault Input
15: PID function disabled
11.11 Multi-function Input
Terminal (MI12)
16: Output shutoff stop 0
17: Parameter lock enable
18: Operation command selection (external
terminals)
19: Operation command selection (keypad)
20: Operation command selection
(communication)
21: FWD/REV command
22: Source of second frequency command
23: Run/Stop PLC Program (PLC1)
(NOT for VFD*E*C models)
23: Quick Stop (Only for VFD*E*C models)
24: Download/execute/monitor PLC Program
(PLC2) (NOT for VFD*E*C models)
