Chapter 4 Parameters
4-10
Group 3 Output Function Parameters
Parameter Explanation Settings
Factory
Setting
Customer
03.00
Multi-function
Output Relay (RA1,
RB1, RC1)
0: No function
8
1: AC drive operational
2: Master frequency attained
3: Zero speed
4: Over torque detection
03.01
Multi-function
Output Terminal
MO1
5: Base-Block (B.B.) indication
1
6: Low-voltage indication
7: Operation mode indication
8: Fault indication
9: Desired frequency 1 attained
10: Terminal count value attained
11: Preliminary count value attained
12: Over Voltage Stall supervision
13: Over Current Stall supervision
14: IGBT overheat warning (ON: 85℃, OFF:
80℃)
15: Over Voltage supervision
16: PID supervision
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
21: Brake control (Desired frequency
attained)
22: Drive ready
23: Desired frequency 2 attained
24 :Function of Output Frequency Control
Multi-output terminal ON/OFF
25: DEB Operation Indication
03.02 Desired Frequency
1 Attained
0.00 to 599.00Hz
0.00
03.03
Analog Output
Signal Selection
(AFM)
0: Analog frequency meter
0
1: Analog current meter
03.04 Analog Output Gain 1 to 200% 100
03.05 Terminal Count
Value
0 to 9999 0
