Chapter 4 Parameters 
4-11
Parameter Explanation Settings
Factory
Setting
Customer
03.06
Preliminary Count
Value
0 to 9999 0
03.07
EF Active When
Terminal Count
Value Attained
0: Terminal count value attained, no EF
display
0
1: Terminal count value attained, EF active
03.08 Fan Control
0: Fan always ON
0
1: 1 minute after AC motor drive stops, fan
will be OFF
2: Fan ON when AC motor drive runs, fan
OFF when AC motor drive stops
3: Fan ON when preliminary heatsink
temperature attained (ON: 60℃, Off: 40℃)
03.09
The Digital Output
Used by PLC
(NOT for VFD*E*C
models)
Read only
##
Bit0=1:RLY used by PLC
Bit1=1:MO1 used by PLC
Bit2=1:MO2/RA2 used by PLC
Bit3=1:MO3/RA3 used by PLC
Bit4=1:MO4/RA4 used by PLC
Bit5=1:MO5/RA5 used by PLC
Bit6=1:MO6/RA6 used by PLC
Bit7=1:MO7/RA7 used by PLC
03.10
The Analog Output
Used by PLC
(NOT for VFD*E*C
models)
Read only
##
Bit0=1:AFM used by PLC
Bit1=1: AO1 used by PLC
Bit2=1: AO2 used by PLC
03.11
Brake Release
Frequency
0.00 to 20.00Hz 0.00
03.12
Brake Engage
Frequency
0.00 to 20.00Hz 0.00
