Chapter 4 Parameters
4-34
Group 12: Analog Input/ Output Parameters for Extension Card
Parameter Explanation Settings
Factory
Setting
Customer
12.00
AI1 Function
Selection
0: Disabled
0
1: Source of the 1st frequency
2: Source of the 2nd frequency
3: PID Set Point (PID enable)
4: Positive PID feedback
5: Negative PID feedback
12.01
AI1 Analog Signal
Mode
0: ACI2 analog current (0.0 ~ 20.0mA)
1
1: AVI3 analog voltage (0.0 ~ 10.0V)
12.02
Min. AVI3 Input
Voltage
0.0 to 10.0V 0.0
12.03
Min. AVI3 Scale
Percentage
0.0 to 100.0% 0.0
12.04
Max. AVI3 Input
Voltage
0.0 to 10.0V 10.0
12.05
Max. AVI3 Scale
Percentage
0.0 to 100.0% 100.0
12.06
Min. ACI2 Input
Current
0.0 to 20.0mA 4.0
12.07
Min. ACI2 Scale
Percentage
0.0 to 100.0% 0.0
12.08
Max. ACI2 Input
Current
0.0 to 20.0mA 20.0
12.09
Max. ACI2 Scale
Percentage
0.0 to 100.0% 100.0
12.10
AI2 Function
Selection
0: Disabled
1: Source of the 1st frequency
2: Source of the 2nd frequency
3: PID Set Point (PID enable)
4: Positive PID feedback
5: Negative PID feedback
0
12.11
AI2 Analog Signal
Mode
0: ACI3 analog current (0.0 ~ 20.0mA)
1
1: AVI4 analog voltage (0.0 ~ 10.0V)
