Delta VFD-E Series User Manual

1-10
Frame D
Remove Extension Card
For Frame A, Frame B, Frame C and Frame D
Loosen the screws first then press and hold in the latches on each side of the extension card
and pull the extension card up to release. On the other hand, it can install the extension card
into the AC motor drive with screws.
1. Press the left and right latches.
2. Remove the fan.
3. Detach the power cord
from the fan.
