B-7

B.2 No-fuse Circuit Breaker Chart

For 1-phase/3-phase drives, the current rating of the breaker shall be within 2-4 times rated

input current.

Model Recommended no-fuse breaker (A)

Fuse Specification

Max. I (A) Min. I (A)

VFD002E11A

1.6~2.6 times of the rated input current

15 15

VFD004E11A 20 20

VFD007E11A 30 30

VFD002E21A 10 10

VFD004E21A 15 15

VFD007E21A 20 20

VFD015E21A 30 30

VFD022E21A 50 50

VFD002E23A 6 6

VFD004E23A 6 10

VFD007E23A 10 15

VFD015E23A 20 25

VFD022E23A 30 35

VFD037E23A 40 50

VFD055E23A 50 60

VFD075E23A 60 80

VFD110E23A 100 125

VFD150E23A 150 180

VFD004E43A 6 6

VFD007E43A 6 10

VFD015E43A 10 15

VFD022E43A 15 20

VFD037E43A 20 30

VFD055E43A 30 40

VFD075E43A 40 50

VFD110E43A 50 60

VFD150E43A 70 90

VFD185E43A 80 100

VFD220E43A 100 125

Delta VFD-E Series User Manual
