Delta VFD-E Series User Manual

Chapter 4 Parameters 
4-146
Content Address Function
Bit 8-15 Reserved
2001H Frequency command
2002H
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Bit 2 External Base Block
Bit 3~15 Reserved
Status
monitor
Read only
2100H
Fault code: low byte
Warning code: high byte
2101H
Status of the motor drive
Bit 0-1
00B: RUN LED is off, STOP LED is on (The AC
motor Drive stops)
01B: RUN LED blinks, STOP LED is on (When
AC motor drive decelerates to stop)
10B: RUN LED is on, STOP LED blinks (When
AC motor drive is standby)
11B: RUN LED is on, STOP LED is off (When
AC motor drive runs)
Bit 2 1: JOG command
Bit 3-4
00B: FWD LED is on, REV LED is off (When AC
motor drive runs forward)
01B: FWD LED is on, REV LED blinks (When AC
motor drive runs from reverse to forward)
10B: FWD LED blinks, REV LED is on (When AC
motor drive runs from forward to reverse)
11B: FWD LED is off, REV LED is on (When AC
motor drive runs reverse)
Bit 5-7 Reserved
Bit 8
1: Master frequency Controlled by
communication interface
Bit 9 1: Master frequency controlled by analog signal
Bit 10
1: Operation command controlled by
communication interface
Bit 11-15 Reserved
