Chapter 4 Parameters
4-15
Parameter Explanation Settings
Factory
Setting
Customer
04.20 Min AVI2 Voltage 0.0 to 10.0V 0.0
04.21 Min AVI2 Frequency 0.0 to 100.0% F max. 0.0
04.22 Max AVI2 Voltage 0.0 to 10.0V 10.0
04.23
Max AVI2
Frequency
0.0 to 100.0% F max. 100.0
04.24
The Digital Input
Used by PLC
(NOT for VFD*E*C
models)
Read only
##
Bit0=1:MI1 used by PLC
Bit1=1:MI2 used by PLC
Bit2=1:MI3 used by PLC
Bit3=1:MI4 used by PLC
Bit4=1:MI5 used by PLC
Bit5=1:MI6 used by PLC
Bit6=1: MI7 used by PLC
Bit7=1: MI8 used by PLC
Bit8=1: MI9 used by PLC
Bit9=1: MI10 used by PLC
Bit10=1: MI11 used by PLC
Bit11=1: MI12 used by PLC
04.25
The Analog Input
Used by PLC
(NOT for VFD*E*C
models)
Read only
##
Bit0=1:AVI used by PLC
Bit1=1:ACI/AVI2 used by PLC
Bit2=1: AI1 used by PLC
Bit3=1: AI2 used by PLC
04.26
Display the Status
of Multi-function
Input Terminal
Read only
##
Bit0: MI1 Status
Bit1: MI2 Status
Bit2: MI3 Status
Bit3: MI4 Status
Bit4: MI5 Status
