Chapter 4 Parameters
4-21
Parameter Explanation Settings
Factory
Setting
Custome
31: Control Board CPU WRITE failure (cF2.1)
32: ACI signal fault (AErr)
33: Reserved
34: Motor PTC overheat protection (PtC1)
35: PG feedback signal fault (PGEr)
36-39: Reserved
40: Communication time-out fault of control
board and power board (CP10)
41: dEb fault
42: ACL (Abnormal Communication Loop)
66: U phase output phase loss (oPHL1)
67: V phase output phase loss (oPHL2)
68: W phase output phase loss (oPHL3)
06.13
Action for detected
Output Phase Loss
(OPHL)
0 : Warn and keep operation
1 : Warn and ramp to stop
2 : Warn and coast to stop
3 : No warning
3
06.14
Deceleration Time of
Output Phase Loss
0.0~120.0 seconds
0.5
06.15
Detected Current
Bandwidth
0~100%
2
06.16
Detected DC Brake
Time of Output
Phase Loss
0.0~120.0 seconds
0.1
