DigiDesign D-Show Profile User Manual

D-Show Profile Guide220
D-Show Stage Rack Specifications (maximum configuration)
Dimensions (H x W x D) 17.5 x 17.0 x 12.2 inches (445 x 432 x 310 mm)
Rack Spaces 10 U
I/O Card Slots 12 (6 input, 6 output)
Weight 86 lbs (39 kg)
Power Requirements 90–260 VAC, 50–60 Hz, 140 W
Snake 1 In/Out Connectors (to FOH Rack) BNC female (2)
Snake 2 In/Out Connectors (to FOH Rack) BNC female (2)
Snake Cable Type 75-ohm coaxial cable
Snake Cable Length 250 ft (76 m) or 500 ft (152 m)
PQ Link Connector (to PQ Rack) XLR4-M
PQ Link Cable Type 110-ohm (digital) cable
Max PQ Link Cable Length 15 ft (4.6 m)
D-Show FOH Rack Specifications (Maximum Configuration)
Dimensions (H x W x D) 17.5 x 17.0 x 15.1 inches (445 x 432 x 384 mm)
Rack Spaces 10 U
Weight 74 lbs (33.7 kg)
Power Requirements 90–260 VAC, 50–60 Hz, 220 W
Snake 1 In/Out Connectors (to Stage Rack) BNC female (2)
Snake 2 In/Out Connectors (to Stage Rack) BNC female (2)
Word Clock In/Out Connectors BNC female (2)
USB Ports (2) USB 2.0
FOH Link Connector (to Main Unit) MIL connector
Max FOH Link Cable Length 11 ft (3.35 m)

DigiDesign D-Show Profile Specifications

General

Brand	DigiDesign
Model	D-Show Profile
Category	Music Mixer
Language	English
