D-Show Profile Guide224
Digital Inputs 1–4
Connector XLR3-F
Format AES/EBU
Word Length 24-bit
Sample Rate 48 kHz
Sample Rate Conversion 3:1 ratio
Digital Outputs 1–4
Connector XLR3-M
Format AES/EBU
Level N/A
Word Length 24-bit
Sample Rate 48 kHz
Sample Rate Conversion Yes
Dithering No
Channel Status Info Pro, Audio 48K, No Emphasis
Snake
Connector (x4) BNC
Cable Type coaxial
Max Length 250 feet (76 m) Belden 1855A
500 feet (152 m) Belden 1694A
Channel Count 48 inputs, 48 outputs
Digital Snake Cable Assemblies
Customers wishing to build their own digital snake assemblies using copper coaxial cable should adhere to the following cable
type and length recommendations:
Check the VENUE sections of the Digidesign website for additional information about cable specifications and options
(www.digidesign.com).
Digital Snake Cable Specifications
SNAKE Connector (x4) BNC Male, 75 ohm
Cable Type Coaxial, 75 ohm
Max Length 250 ft (76 m)
Belden 1855A - single conductor
Belden 7787A - three conductor
Belden 7788A - four conductor
Max Length 500 ft (152 m)
Belden 1694A - single conductor
Belden 7710A - three conductor
Belden 7711A - four conductor
Van damme Cable (VDC) 278-175-00 - single conductor
