DigiDesign D-Show Profile - Stage Rack; FOH Rack

D-Show Profile Guide222
Stage Rack
SRI Analog Input Card
Connector (x8) XLR3–F
Phantom Power +48V (individually switchable per channel via software)
Maximum Input Level +34 dBu, with pad *
Pad 20 dB
Gain +10 dB to +60 dB
Input Impedance pad off: 10 k ohm balanced
pad on: 4 k ohm, balanced
EIN 126 dBu typ (Max gain, 150 ohm source, 22 Hz – 20 kHz BW) *
LEDs signal presence (indicates –37 dBu or greater), +48V
A/D 24-bit, delta sigma
SRO Analog Output Card
Connector (x8) XLR3–M
Maximum Output Level +24 dBu *
Output Impedance 50 ohm
LEDs signal presence (indicates –37 dBu or greater), mute
D/A 24-bit, delta sigma, 128x oversampling
* 0 dBu = 0.775 V rms
FOH Rack
FOH Rack IO (Standard)
Com Input
Connector Neuetrik combi XLR/TRS
Phantom Power +15V @ 6mA (switchable on FOH Rack back panel)
Gain –2 dBu to –32 dBu, 6 steps
Input Impedance 20K ohms
Analog Inputs 1–8; 2-Track Analog Inputs
Connector 1/4-inch TRS
Maximum Input Level +24 dBu
Input Impedance 10K ohms
Analog Outputs 1–8; 2-Track Analog Outputs, Monitor L/R
Connector 1/4-inch TRS
Maximum Output Level +24 dBu
Output Impedance 50 ohms
See the Expansion Options Guide for audio specifications on Stage Rack expansion options.
