Chapter 25: Mechanical Specifications 219
Chapter 25: Mechanical Specifications
D-Show Profile Mechanical Specifications
Maximum Height (front) 3.2 inches (81 mm)
Maximum Height (rear) 6.8 inches (169 mm)
Maximum Width 45.21 inches (1150 mm)
Maximum Depth 31.11 inches (790 mm)
Weight 90 lbs (40.823313 Kg)
Power Requirements 100–240 VAC, 50–60 Hz, 160 W
USB Ports (3) USB 1.1
VGA Port DB-15 mini-female (1024 x 768 resolution)
Footswitch Connectors (2) 1/4-inch TRS
GPI In Port DB-25 D-Sub, female
GPI Out Port DB-25 D-Sub, male
Console Light Connectors (2) XLR
FOH Link Connector (to FOH Rack) MIL connector
Max FOH Link cable length 11 ft (3.35 m)
D-Show Profile dimensions
45.21
6.831.11
