Chapter 3: D-Show Proﬁle Control Overview 25

Chapter 3: D-Show Proﬁle Control Overview

D-Show Proﬁle Top Panel

The following figure identifies the main sections of the D-Show Profile control surface:

D-Show Profile provides 24 bankable input channel strips in Input Channel sections, the Assignable Channel Section (ACS), eight

bankable output channel strips plus a Mains fader in the Output Masters section, as well as global controls and comprehensive me-

tering.

Figure 7. D-Show Proﬁle control surface

Global

A Input Channels 1–16 and 17–24

A A

Bus Output Mains

Meters

B Assignable Channel Sections (ACS)

C Output Masters Section

D Master and Global Controls

Modifiers

Main Page

Default Chapter3
