(38) Remove #9 thrust washer from rear planetary
gear assembly (Fig. 38).
(39) Remove rear planetary gear assembly (Fig.
39).
(40) Remove #10 thrust washer (Fig. 40).
Fig. 37 Sun Gear Driving Shell Components
1 - #8 THRUST WASHER (STEEL)
2 - #7 SPACER (STEEL)
3 - SUN GEAR
4 - SUN GEAR DRIVING SHELL
5 - SNAP RING
Fig. 38 No. 9 Thrust Washer
1 - #9 THRUST WASHER
2 - OUTPUT SHAFT
3 - REAR PLANETARY GEAR ASSEMBLY
Fig. 39 Rear Planetary Gear Assembly
1 - REAR PLANETARY GEAR ASSEMBLY
Fig. 40 No. 10 Thrust Washer
1 - OVERRUNNING CLUTCH CAM ASSEMBLY
2 - #10 THRUST WASHER
PL 31TH AUTOMATIC TRANSAXLE 21s - 33
31TH AUTOMATIC TRANSAXLE (Continued)
