(54) Using setup as shown in (Fig. 63), remove
output gear bearing cone.
(55) Remove rear carrier assembly from transaxle
(Fig. 64).
(56) Remove rear carrier assembly bearing cone
using setup shown in (Fig. 65).
(57) Install low/reverse spring compressor tool as
shown in (Fig. 66) (Fig. 67).
Fig. 63 Remove Bearing Cone
1 - TOOL 5048 WITH JAWS 5048–5 AND BUTTON L-4539–2
2 - WRENCHES
3 - OUTPUT GEAR
Fig. 64 Remove Rear Carrier Assembly
1 - REAR CARRIER ASSEMBLY
Fig. 65 Remove Rear Carrier Bearing Cone
1 - TOOL 5048 WITH JAWS 5048–3 AND BUTTON 6055
2 - WRENCHES
3 - REAR CARRIER ASSEMBLY
Fig. 66 Low/Reverse Spring Compressor Tool
1 - TOOL 6057
2 - TOOL 5059
3 - TOOL 5058–3
PL 41TE AUTOMATIC TRANSAXLE 21s - 91
41TE AUTOMATIC TRANSAXLE (Continued)
