(61) Using ordinary pliers, remove pivot shaft and
guide bracket assembly (Fig. 71).
(62) Inspect guide bracket components for exces-
sive wear and replace if necessary (Fig. 72).
(63) Remove low/reverse clutch piston (Fig. 73).
(64) Remove low/reverse piston retainer-to-case
screws (Fig. 74).
Fig. 71 Pivot Shaft and Guide Bracket
1 - ANTIRACHET SPRING
2 - GUIDE BRACKET
3 - PIVOT SHAFT
4-PAWL
Fig. 72 Guide Bracket Disassembled
1 - ANTIRATCHET SPRING
2 - GUIDE BRACKET
3 - SPLIT SLEEVE
4 - SPACER
5 - STEPPED SPACER
6-PAWL
Fig. 73 Remove Low/Reverse Clutch Piston
1 - LOW/REVERSE CLUTCH PISTON
2 - D-RING SEAL
3 - D-RING SEAL
Fig. 74 Remove Piston Retainer Attaching Screws
1 - LOW/REVERSE CLUTCH PISTON RETAINER
2 - SCREWDRIVER
3 - TORX-LOC SCREWS
PL 41TE AUTOMATIC TRANSAXLE 21s - 93
41TE AUTOMATIC TRANSAXLE (Continued)
