(4) Install the OD/Reverse piston assembly to the
input clutch retainer as shown in (Fig. 226).
(5) Install the input hub/shaft assy. to the OD/Re-
verse piston/clutch retainer assy. (Fig. 227).
(6) Install input hub tapered snap ring (Fig. 228).
(7) Install UD clutch piston (Fig. 229).
Fig. 226 Install OD/Reverse Piston
1 - PUSH DOWN TO INSTALL OVERDRIVE/REVERSE PISTON
2 - INPUT CLUTCHES RETAINER
Fig. 227 Install Input Shaft Hub Assembly
1 - PUSH DOWN TO INSTALL INPUT SHAFT HUB ASSEMBLY
(ROTATE TO ALIGN SPLINES)
2 - OD/REV. PISTON
Fig. 228 Install Input Hub Tapered Snap Ring
1 - INPUT SHAFT
2 - INPUT HUB SNAP RING (TAPERED SIDE UP WITH TABS IN
CAVITY)
3 - SNAP RING PLIERS
Fig. 229 Underdrive Clutch Piston
1 - PISTON
21s - 162 41TE AUTOMATIC TRANSAXLE PL
INPUT CLUTCH ASSEMBLY (Continued)
