User’s Manual
56
6.3.2 Re-sort
The Re-sort function helps to rearrange display of camera images from all
connected sites listed in the site tree. The first channel of the first connected
site will be displayed in the first grid and so on from top to the bottom.
There are other ways to change displaying grids for channels / sites. Refer to
the following descriptions.
Assign a Channel / Site to Certain Grid(s)
CMS allows users to assign any channel / site in the site tree to any grid of
CMS main window. Follow steps below to complete assignment.
Step 1: Click and hold the channel / site users want.
Step 2: Drag and drop it onto the grid that users want to assign to.
Remove Display Grids
Users can also remove any channel by right
clicking on the grid and select <Remove>. Or
users can select any grid and press <Delete>
key on the keyboard to remove the channel.
Note that the Re-sort function will restore the
removed channels.
